5 Layers and Instruments | 67
anchor symbol permanently.
3. If you want to switch back to the non-anchored mode, click the cursor label
again.
To switch the synchronization cursor
When synchronizing instruments, a synchronization cursor automatically
appears in the oscilloscope. By default, the active cursor within the visible range
is used as synchronization cursor. For more information, see "Synchronization
timestamp" on page89. To see how you can zoom, synchronize, and scroll in
instruments, watch our video Navigating in Instruments.
The synchronization cursor is marked by a synchronization symbol at the bottom
of the cursor line .
To switch the synchronization cursor, click the line of the other cursor. Altern-
atively, you can press CTRL+1.
The cursor becomes active and is used as synchronization cursor. Thus, the
timestamp that is used for indicating the synchronization changes in all other
instruments. For example, in other oscilloscopes the synchronization cursor is
also switched accordingly.
If you have selected the sample-wise navigation mode, the instrument in which
you have performed the last action provides this sample information. In an oscil-
loscope, this is indicated by the dark blue background color of the cursor label. All
other synchronized oscilloscopes are shown with transparent cursor labels .
To hide and unhide the cursor's tooltips
1.
Click or use the tab Instrument in the Properties window.
2. To hide the tooltips, select Hide Cursor's Values Tooltips.
3.
To unhide them again, click and select the respective entry.
To copy the signal values at cursor's position
To copy the signal values from a specific point in time to the clipboard, do the fol-
lowing:
1. Show the cursor by selecting Show/Hide Cursors in the cursors' drop-
down menu .
2. Move the cursor to the position of interest.
3. Right-click on the desired signal in the signal list and select Copy
contents.
The content of the visible columns and columns header are copied in the
clipboard.
To change the number of decimals of the cursor's tooltips
The number of decimals of the cursor tooltip is defined by the number of decim-
als for the respective signal. For more information, see "To change the number of
decimals" on page56.
MDA V8 | User Guide
