Basic Manual Control 155
Modifying a Terminated Channel Selection
It is possible to add or remove channels from a previously terminated command line. You will need to
first press [+] or [-] and then you can add to or remove from your current channel selection. This
includes selecting channels from the direct selects, summary view, and Magic Sheets.
Using Groups as a Channel Collector
[Group] can be used as a quick way to collect channels from submasters, cues, palettes, or presets.
SeeAbout Groups (on page186) for more information.
The following actions are possible:
[Group] [Cue] [1] - selects all the channels in cue 1.
[Group] [Sub] [3] - selects all the channels in submaster 3.
[Group] [Int Palette] [5] - selects all the channels in intensity palette 5.
[Next] and [Last]
The [Next] and [Last] buttons increment and decrement channel selection. If only one channel is
selected, [Next] increments the channel selection to the next sequential channel, while [Last] decre-
ments the channel selection by one.
For Example:
Select channel 10 then change the selection to channel 11 using the [Next] key:
[1] [0] [Enter]
Channel 10 is selected with a gold outline around the entire channel and the channel
number is indicated in white.
[Next]
Channel 11 is now selected with a gold outline and white channel number while channel 10
is no longer selected.
When a group of channels is selected, pressing [Next] or [Last] selects the first or last channel in the
channel list.
For Example:
Channels 11 through 20 are selected:
[Next]
Channels 11 through 20 are still the specified channel list but only channel 11 is selected for
control. You can now sequentially press [Next] or [Last] to cycle through the list. Press
[Select Last] to reselect the entire range.
