4.2. Things to Know About Signal Routing
There are a few general “rules” about signal routing in the H9000 which are useful to keep in mind.
You can only use one of the following digital audio protocols at any given time:
AES3 (AES/EBU) over the DB25 connector
AES3 (AES/EBU) over the XLR connector
S/PDIF over the optical connector
S/PDIF over the RCA connector
ADAT over the optical connector
When using S/PDIF over the optical ADAT connectors, you can only work at sample rates of
44.1kHz and 48kHz. 88.2kHz and 96kHz are not supported.
FX chains support 32 inputs and 32 outputs. The outputs of an FX chain can be “multed” to an
arbitrary number of physical Input/Output channels, computer audio interface channels, etc.
4.3. Sessions
A Session is the “big picture” for the H9000, a snapshot of the current state of all settings on the unit.
•
◦
◦
◦
◦
◦
•
•
