Even though there are only two pedal/switch connectors on the H9000, you can connect up to
four pedals. This is made possible by connecting two pedals to each connector using a “Y” cable
such as the “Hosa YPP-117 ¼-inch TRS to Dual ¼-inch TSF Stereo Breakout cable”.
This capability is possible because:
In the external control section of the Parameters mode, there are 4 expression pedals listed.
In set-up mode, there are options to congure a single connector to be connected to two
separate expression pedals.
2.1.7.3. Control Voltages
The H9000 can also be controlled using up to 4 control voltage sources. To do so, follow the
instructions for setting up and calibrating an expression pedal. CV 1+2 will correspond to the TIP and
RING of Expression Pedal 1, CV 3+4 will correspond to the TIP and RING of Expression Pedal 2.
2.1.8. MIDI
The MIDI screen displays options to enable and disable MIDI feedback.
•
•
2. Setup
Copyright © 2021, Eventide Inc.
