NAV IP Access controller
14
Note:Ifthescrewholesofthecontrollerdonotlineupproperlywiththeenclosure,
somefillingmayberequiredforadjustment.

1. Usethesuppliedmountingtemplatetopositiontheholesforthesupportframesand
thenmountthetwosupportframesonawall.


Figure2‐2

Note:Ifusingthemetalenclosure,usethefourpre‐drilledholesonthebackwallof
theenclosureandthenmountthetwosupportframesontheinteriorofthe
enclosure.

2. Mountthecontrollerbaseboardtothesupportframes.

Figure2‐3

a. Placethecontrollerbaseboardonthesupportframes.Lineupthefourlatches
onthesupportframeswiththeholesonthecontrollerbaseboard.Oncelinedup,
slidethecontrollerbaseboarddowntosecureitinplace.
b. Securethecontrollerbaseboardtothesupportframesusingthesuppliedtwo
screws.

