NAV IP Access controller

15
3. Installandmountadditionaldoormodulesorthealarmmodule.
Note:Thecontrollercanhookupto4doormodulesandonly1alarmmodule.Each
doormoduleiscascadedtoitsleftsidemoduletillthemainmodule.Thedoor
modulesandthealarmmodulecanbeplacedinanysequence.

a. Connectthepinsonthelowerrightcornerofthenewmoduletotheconnector
onthebottomleftcorneroftheinstalledmodule.Makesurethatthepinsfit
snuglyintothereceivingmodule.

Figure2‐4

b. Securethemoduletothecontrollerbaseboardusingthethreescrewsprovided
inthemodulepackage.

Figure2‐5

TheReader/DoorIndexConversion
