Evolis Avansia User Manual

34
Ï
When [Remove cards] is diplayed, open the top cover.
Ð
Open the cards feeder and remove the cards from the cassette.
Ñ
When [Set Cleaning Crd] is displayed, load the cleaning card in the feeding slot. Align the adhesive side of the cleaning
card to the right.
Ò
Close the cards feeder and the top cover.
Ó
When [SET:Start] is displayed, press the SET Key. The cleaning starts automatically.
When [Complete] is diplayed, cleaning is completed and the cleaning card is ejected into the cards ejection slot.
Put the lm back in the Retransfer module. Your printer is once again ready to use.
3
Ï Ð Ñ
Ó
The adhesive side is
on the rear surface
Cleaning
SET:Start
Cleaning... Complete
SET

Evolis Avansia Specifications

General

Color	Yes
Card size	85.6 x 53.98 mm
Card types	Polycarbonate, PVC, PVC Composite
Print technology	Dye-sublimation/Resin Thermal transfer
Print speed (color)	144 card/h
Card thickness (min)	0.76 mm
Duplex print speed (color)	96 card/h
Display	LCD
Lamination	-
Certification	CE, FCC, UL, IEC RoHS
Product color	Black, White
Internal memory	64 MB
Cable lock slot type	Kensington
Total input capacity	250 sheets
Wi-Fi	No
Security algorithms	IPSEC
Ethernet interface type	Fast Ethernet
Bundled software	cardPresso XXS
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	297 mm
Width	340 mm
Height	436 mm
Weight	20000 g
