Evolis Avansia User Manual

38
3-5 Servicing the reverse roller
Recommended cleaning cycle: If card delivery from the reverse section to the secondary transfer feeding roller
is not possible, then clean the Reverse Roller.
Ê
Turn off the printer.
Ë
Open the top cover and remove card feeder.
Ì
Open the front cover and the trapdoor cover.
Í
Rotate the reverse wheel.
Î
Locate the reverse section roller as shown.
Ï
Wipe the roller clean with an Evolis’ wipe as shown.
Ð
Rotate the reverse leading wheel and fully clean the roller.
Ñ
Close the front cover.
Ò
Return the card feeder and close the top cover. Your printer is once again ready to use.
Wait for 2 minutes after cleaning before using your printer.
3
Í ÏË Ì
Reverse
Wheel
Reverse Feeding
Wheel
Cloth
Reverse Roller

Evolis Avansia Specifications

General

Color	Yes
Card size	85.6 x 53.98 mm
Card types	Polycarbonate, PVC, PVC Composite
Print technology	Dye-sublimation/Resin Thermal transfer
Print speed (color)	144 card/h
Card thickness (min)	0.76 mm
Duplex print speed (color)	96 card/h
Display	LCD
Lamination	-
Certification	CE, FCC, UL, IEC RoHS
Product color	Black, White
Internal memory	64 MB
Cable lock slot type	Kensington
Total input capacity	250 sheets
Wi-Fi	No
Security algorithms	IPSEC
Ethernet interface type	Fast Ethernet
Bundled software	cardPresso XXS
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	297 mm
Width	340 mm
Height	436 mm
Weight	20000 g
