Test Setup - Test Configurator, Timer, and System
NetBlazer 193
Network Details (iSAM)
Services
Allows the selection of the number of services: 1 (default) to 4.
The following parameters are configurable individually for each service:
Profile
Two profiles are defined by default as well as User Profile. Profiles are
user definable and up to 25 profiles can be predefined (see
Customizable Profiles on page 198).
Profile Parameter
Frame Type Frame Sizes VLAN Priority DSCP Performance Criteria
Priority EMIX 64, 128, 512, 1024,
and 1518
a
a. The minimum frame size value is adjusted according to the frame structure and components selected as
shown in the table of Frame Size on page 195.
7CS7
b
b. ECN is not present and not configurable but is set to 00 (Not-ECT).
MEF Metro High
Best Effort 0 CS0
b
MEF Metro Low
