Extreme Networks ExtremeSwitching 5420 Series Installation Guide

Power Supplies for Use with Your
Switch
150 W AC Power Supply on page 35
600 W AC PoE Power Supply on page 36
920 W AC PoE Power Supply on page 36
1200 W AC PoE Power Supply on page 37
2000 W AC PoE Power Supply on page 37
5420F models have 1 hot-swappable PSU and 1 xed PSU. 5420M models have 2 hot-
swappable PSUs. You can remove one power supply without interrupting the switch's
operation.
Power supplies are ordered separately.
For more information, see the following topics:
• 150 W AC Power Supply on page 35
• 600 W AC PoE Power Supply on page 36
• 920 W AC PoE Power Supply on page 36
• 1200 W AC PoE Power Supply on page 37
• 2000 W AC PoE Power Supply on page 37
150 W AC Power Supply
The 150 W AC power supply (Model XN-ACPWR-150W with front-to-back
ventilation airow) is compatible with 5420F-24T-4XE, 5420F-24S-4XE, 5420F-48T-4XE,
5420M-24T-4YE, and 5420M-48T-4YE switch models.
The 150 W AC power supply has a keyed power inlet (C14) that requires a (C13) power
cord.
The 150 W AC power supply has the status LEDs listed in the following table:
Table 4: 150 W AC Power Supply LED Status Indications
LED State Description
Off No AC input power connection
Green Output ON and OK
ExtremeSwitching 5420 Series Hardware Installation Guide 35
