The 920 W AC PoE power supply has the status LEDs listed in the following table:
Table 6: 920 W AC PoE Power Supply LED Status Indications
DC_OK
(left)
AC_OK
(right)
Description
Green/1
Hz
ashing
Green AC present / only standby outputs on.
Green Green Power supply DC outputs on and OK.
Red Green Power supply failure. PSU shut down*.
*Power supply DC fail : OCP, OVP, OTP, fan.
1200 W AC PoE Power Supply
The 1200 W AC PoE power supply (Model XN-ACPWR-1200W with front-to-back
ventilation airow) is compatible with 5420F-16W-32P-4XE and 5420F-16MW-32P-4XE
switch models.
The 1200 W AC PoE power supply has a keyed power inlet (C16) that requires a notched
(C15) power cord.
The 1200 W AC PoE power supply has the status LEDs listed in the following table:
Table 7: 1200 W AC PoE Power Supply LED Status Indications
DC_OK
(left)
AC_OK
(right)
Description
Green/1
Hz
ashing
Green AC present / only standby outputs on.
Green Green Power supply DC outputs on and OK.
Red Green Power supply failure. PSU shut down*.
*Power supply DC fail : OCP, OVP, OTP, fan.
2000 W AC PoE Power Supply
The 2000 W AC PoE power supply (Model XN-ACPWR-2000W with front-to-back
ventilation airow) is compatible with 5420M-48W-4YE and 5420M-16MW-32P-4YE
switch models.
In order to obtain 2000W output from this power supply, the PSU must be connected
to a 200-240VAC source.
The 2000 W AC PoE power supply has a keyed power inlet (C16) that requires a notched
(C15) power cord.
Power Supplies for Use with Your Switch 1200 W AC PoE Power Supply
ExtremeSwitching 5420 Series Hardware Installation Guide 37
