Setting Description
Erase Heat Offset
Adjust the Erase temperature for the rewriteable cards as needed.
Increase the Current Setting to cause more heat to be used in
the erasing process.
OR
Decrease the Current Setting to cause less heat to be used in
the erasing process.
Note: Erase Heat Offset provides user ability to control the
Printhead heat level when the Erase Operation is performed.
Appropriate heat levels should be applied for the proper erase
process. This setting should be adjusted for proper erasure.
Write Heat Offset
Adjust the Write temperature for the rewriteable cards as needed.
Increase the Current Setting to cause more heat to be used in
the printing process of a rewritable card.
OR
Decrease the Current Setting to cause less heat to be used in
the printing process of a rewritable card.
Note: Write Heat Offset provides user capability to control the
printhead heat level when the Write Operation is performed.
Appropriate heat levels should be applied for the proper writing
process.
Flipper Home Offset
This setting is a calibration driven value and should not be
adjusted. If the Flipper unit is replaced and has not been
calibrated this value may need to be adjusted.
Note: This is factory set and should not be changed unless
directed by a technician..
Flipper Eject Height
Offset
This setting is a calibration driven value and should not be
adjusted. If the Flipper unit is replaced and has not been
calibrated this value may need to be adjusted.
Note: This is factory set and should not be changed unless
directed by a technician.
Mag Super-Co Voltage
Offset
This option changes the voltage going the magnetic head.
Note: This is factory set and should not be changed unless
directed by a technician.
Mag Medium-Co Voltage
Offset
This option changes the voltage going the magnetic head.
Note: This is factory set and should not be changed unless
directed by a technician..
