Faro Focus Premium - Page 139

Laser (Optical Transmitter)
Laser class Laser class 1
Wavelength 1553.5 nm
Pulse duration Approx. 4 ns
Repetition rate Approx. 125 MHz
Optical power approx. 800 mW
Beam divergence Typical 0.3 mrad (0.024°)(1/e)
Beam diameter at exit Typical 2.12 mm (1/e)
Data Handling and Control
Data storage
SATA 3.0 SSD 128 GB
SDXC V30 64 GB SD Card
SD3.0, UHS-I / SDXC / SDHC, max. 512 GB
Scanner control
Touch screen display and WLAN connection.
Control by FARO Stream app (iOS & Android) or mobile
devices with HTML5.
Ranging Unit
Distance accuracy: 1 mm (0.039 in)
Angular accuracy
Horizontal: 19 arcsec
Vertical: 19 arcsec
FARO recommends that you perform on-site compensation
if the unit is exposed to extreme temperatures or mechanical
stress
Unambiguity interval
614 m for up to 0.5 Mio. pts/s;
307m at 1 Mio. pts/s;
FARO
®
Focus Premium Laser Scanner User Manual
Chapter 9: Technical Data
FARO Focus Premium (March 2022) Page132of157
