1. Open the scanner's battery compartment cover.
2. Turn the battery so that its type label is directed upwards.
3. Point the battery contacts toward the scanner.
4. Push the battery straight in, sliding it into the battery compartment until the fastener clicks into
position.
NOTICE: Never apply force while inserting the battery. If the battery does not slide gently into
place, check again for correct alignment.
Figure 5-1 FAROFocus Premium with Battery
5. Connect the cable of the power-supply unit to the power socket of the FAROFocus Premium.
NOTICE: If you use force while inserting the plug in a wrong direction, the plug and the
FAROFocus Premium can be damaged.
6. Connect the AC power cable to the power-supply unit and a power outlet. Check the input voltage
on the type label before connecting.
7. If the FAROFocus Premium is turned off, the scanner LEDs start blinking while charging. The
LEDs stop blinking and illuminate a constant green, when the battery is fully charged.
8. If the FAROFocus Premium is turned on, check the battery's charging state in the scanner's user
interface under Manage > General Settings > Power Management.
