Farr HD8625 - Hydraulic Supports

Technical Manual
hD8625 8-
5
/
8
” 35K Tong
5.23
hyDraulic supporTs
Item Type Description Qty Part Number
A Part
1/2”UNCx4-1/2”HexBolt 2
B Part
HydraulicValveMountPost 2 101-0116
C Part
3/8”NCx1”HexBolt 6 09-1046
D Part
3/8”NCx2”HexBolt 2 09-
E Part
AdjustablePlate-DischargeLineSupport 1 101-0277
F Part
3/8”CarbonSteelLockWasher 4 09-5106
G Part
DischargeLineSupportMountingPlate 1 101-0023
H Part
DischargeLineSupportMountingBase 1 101-0021
J Part
1/2”CarbonSteelLockWasher 2 09-
K Part
AdjustablePlate-InletLineSupport 1 101-0022
L Weldment
InletLineSupportMountingBase 1 101-1138
M Part
3/8”UNCThinNylockNut 6 09-
N Part
3/8”NarrowFlatWasher 6 09-5124
P Part
3/8”NCx1-1/4”HexBolt 2 09-1048
