Farr HD8625 - Pinion Assembly

Technical Manual
hD8625 8-
5
/
8
” 35K Tong
5.13
pinion asseMbly
Item Type Description Qty Part Number
A Part
1/8”NPT90DEGGreaseFitting 4 02-0093
B Part
1/2”NCx1-1/2”HexBolts 8 09-1170
C Part
1/2”LockWashers 8 09-5110
D Part
PinionBearingCap 2 1050-89
E Part
PinionBearing 2 1234-08-01B
F Part
HighPinionGear 1 997-A4-87B
G Part
PinionGearShaft 1 997-A7-86B
H Part
LowPinionGear 1 997-A5-88
