Farr HD8625 - Illustration 2.B.3: Major Component Identification

2.6
hD8625 8-
5
/
8
” 35K Tong
Technical Manual
Item Description
12
TongDoorAssembly
13 TongDoorSpringCylinder
14 BrakeBandAdjustment(topadjustmentshown-bottomadjustmentisidentical)
15 BrakeBand(topbrakebandshown-bottombrakebandisidentical)
16 ManualShiftAssembly
17 TorqueGaugeMount
18 Shifter/GearTrainInspectionPanel
19 HydraulicValveAssembly
20 HydraulicMotor
21 MotorMount
22 SnubLineShackle
IllustratIon 2.B.3: major ComPonent IDentIfICatIon 03
seTup & operaTion
19
20
18
21
22
15
14
16
17
12
13
