Farr HD8625 - Illustration 2.D.2: Hydraulic Connections; Tong; Backup Jaw Availability & Installation; Availability

2.10
hD8625 8-
5
/
8
” 35K Tong
Technical Manual
Thesehosecouplingsareself-sealing,andcareshouldbetakentoensurecompleteengagementtopreventpartialclosureofthecheck
valveinthecoupling.Ensurethatthenut(female)sideiscompletelymadeupontothemaleconnector-thereisalineonthemalefitting
thatindicatescompletemake-up.Snugthefemalefittingrightuptotheline.
IllustratIon 2.D.2: HyDraulIC ConneCtIons 02
MAXIMUM RATED TORQUE FOR THE 2-3/8” JAW DIE KIT IS 18,000 LBS.-FT.
E. TONG / BACKUP JAW AVAILABILITY & INSTALLATION
1. Availability
Thefollowingtablelistsalljawdiekitsthatareavailableasstandardsizesforthismodeloftong.McCoyDrilling&Completions|Farr
offersagoodselectionofstandardjawsizes.However,pleasenotethatwecancustom-engineerandmanufactureanysizeofjaw
withintherangeofthetong.Jawsystemsareavailabletoallowuseofdieinsertsintendedforspecializedapplications.Calloursales
officeforinformationonjawanddiesystemsdesignedforhigherorlowergrip,ornon-markingapplications.
Thetablelistsstandardflatandcontoureddovetaildieinsertsthatareavailableasspareparts.However,awidevarietyofdiamond-
tooth,GRITFACE®,aluminium,andwrap-aroundfine-toothdiesareavailableforspecializedapplications.Pleaserefertoourwebsite
forcompleteinformation:
http://www.mccoyglobal.com/dies-inserts
seTup & operaTion
Description Part Number Description Part Number
2-3/8”JawDieKit(SeeNoteBelow)
8625-JDK-105
A
6”JawDieKit 8625-JDK-143
2-7/8”JawDieKit
8625-JDK-110
B
6-1/2”JawDieKit 8625-JDK-144
3-1/2”JawDieKit
8625-JDK-115
C
6-5/8”JawDieKit 8625-JDK-145
4”JawDieKit 8625-JDK-120 7”JawDieKit 8625-JDK-150
4-1/2”JawDieKit 8625-JDK-130 7-5/8”JawDieKit 8625-JDK-155
5”JawDieKit 8625-JDK-135 7-3/4”JawDieKit 8625-JDK-160
5-1/2”JawDieKit 8625-JDK-140 8-5/8”JawDieKit 8625-JDK-162
A-UsescontouredinsertPN12-0004
B-UsesdieinsertPN12-0007
C-UsescontouredinsertPN12-0011
AllotherjawdiekitsuseflatdiePN13-0008-314-0
IMPROPERLY MADE CONNECTIONS WILL CONSTRICT OR COMPLETELY OBSTRUCT FLOW
Make up female fitting to
Marked point on male fitting
