Farr HD8625 - Page 15

Technical Manual
hD8625 8-
5
/
8
” 35K Tong
1.3
specificaTions
REPLACEMENT FASTENERS (BOLTS, NUTS, CAP SCREWS, MACHINE SCREWS, ETC.)
MUST BE GRADE 8 OR EQUIVALENT (WHERE REQUIRED).
** These are ideal values. Actual achieved torque is highly dependant upon tong efficiency
and final position of rotary gear when full torque load is reached.
 Hydraulic Requirements (max.): 60USGPM@1000psi
  (189LPM@6.9MPa)
  10USGPM@3000psi
  (38LPM@20.7MPa)
 Length (Doors Closed): 54-1/4”inches/137.8cm
 Height: 53”/134.6cm
 Width: 30”/76.2cm
 Space Required on Pipe: 8”/20.3cm
 Torque Arm Length: 36inches/91.4cm
  -Centrelineofpipetocentrelineofloadcell-
 Weight (Approximate): 1550lb./705kg.
 Available Jaw Sizes: SeePg.2.10
Torque Table **
Pressure High Gear/High Speed Low Gear/Low Speed
PSI / MPa Lbs.-ft. Nm Lbs.-ft. Nm
1000/6.89 200 271 9400 12745
1500/10.34 400 542 16100 21829
2000/13.78 500 678 22800 30913
2500/17.23 700 949 29500 39997
3000/20.67 800 1085 36200 49081
MAXIMUM RATED TORQUE: 35000 LBS.-FT. / 47454 Nm
Speed Table
Gear / Displacement
Flow (GPM/LPM) Low/Full Low/Half High/Full High/Half
10/38 2 4 4 19
20/76 4 8 8 39
40/152 8 15 15 77
60/228 12 23 23 116
