Fastus D4RF Series - Page 133

6-11
1
2
3
4
5
6
Appendix
Index List
Category Name
Index No.
DEC (HEX)
Sub
index
No.
Read/
Write
*1
Backup Format
Length
in
bytes
Default Setting details Remarks (Unit)
Diagnosis Operating hours: Total
operating hours
190 (0xBE) 1 R UINT 4
Operating hours:
Operating hours since
last reset
2 R UINT 4
Identication Find me
*2
204 (0xCC) 0 R/W UINT 1 0 0x00: Find me deactivated
0x01: Find me activated
General
Settings
Preset number 222 (0xDE) 0 R/W UINT 1 1 1 to 5
Observation System status 226 (0xE2) 0 R UINT 2 Bit 6: Received light alarm output
0: Alarm not active
1: Alarm active
Bit 7: Input signal status Pin 2
0: External input OFF
1: External input ON
General
Settings
Notication handling 227 (0xE3) 0 R/W
✓
UINT 1 0 0x00: All enabled
0x01: All disabled
0x02:
Events enabled, PD invalid
ag disabled
0x03: Events disabled, PD invalid
ag enabled
Display setting:
Display mode, channel 1
234 (0xEA) 1 R/W
✓
UINT 1 0 0x00: Value (absolute)
0x01: Bar graph
0x02: Percentage value
0x03: Counter value
0x04: Edge value
Display setting:
Display mode, channel 2
2 R/W
✓
UINT 1 0 0x00: Value (absolute)
0x01: Bar graph
0x02: Percentage value
0x03: Counter value
0x04: Edge value
Display setting: Display
brightness
3 R/W
✓
UINT 1 100 10 to 100
Display setting: Eco
mode
4 R/W
✓
UINT 1 0 0x00: O󰀨
0x01: On
Display setting: Rotate
display
5 R/W
✓
UINT 1 0 0x00: O󰀨
0x01: On
Display setting: Invert
display
6 R/W
✓
UINT 1 0 0x00: O󰀨
0x01: On
Display setting: Alarm
display
7 R/W
✓
UINT 1 0 0x00: O󰀨
0x01: On
Display setting:
Language
8 R/W
✓
UINT 1 1 0x01: English
0x06: Spanish
0x07: Simplied Chinese
0x08: Japanese
0x0A: Korean
Display hold setting:
Hold mode, channel 1
235 (0xEB) 1 R/W
✓
UINT 1 0 0x00: O󰀨
0x01: Peak/bottom
0x02: Peak
0x03: Bottom
0x04: Time
Display hold setting:
Hold mode, channel 2
2 R/W
✓
UINT 1 0 0x00: O󰀨
0x01: Peak/bottom
0x02: Peak
0x03: Bottom
0x04: Time
Smart task Counter mode 1001
(0x3E9)
0 R/W
✓
UINT 1 2 0x00: Up
0x01: Down
0x02: OFF
Preset mode 1002
(0x3EA)
0 R/W
✓
UINT 1 0 0x00: Preset internal disabled
0x01: Preset internal enabled
Preset value 1003
(0x3EB)
0 R/W
✓
UINT 2 0 0 to 16383
Comparator value low 1004
(0x3EC)
0 R/W
✓
UINT 2 10 0 to 16383
Comparator value high 1005
(0x3ED)
0 R/W
✓
UINT 2 10 0 to 16383
Counter value 1006
(0x3EE)
0 R UINT 2
Filtering time 1 1033
(0x409)
0 R/W
✓
UINT 4 0 0 to 30000000
Received light level D1 1034
(0x40A)
0 R UINT 2
Filtering time 2 1035
(0x40B)
0 R/W
✓
UINT 4 0 0 to 30000000
Received light level D2 1036
(0x40C)
0 R UINT 2
Input selector 1 1081
(0x439)
0 R/W
✓
UINT 1 0 0x00: Qint. 1
0x01: Qint. 2
0x64: Ext. input 1
