Fastus D4RF Series - Page 134

6-12
Index List
Category Name
Index No.
DEC (HEX)
Sub
index
No.
Read/
Write
*1
Backup Format
Length
in
bytes
Default Setting details Remarks (Unit)
Smart task Input selector 2 1082
(0x43A)
0 R/W
✓
UINT 1 1 0x00: Qint. 1
0x01: Qint. 2
0x40: Ext. input 1
Logic 1 1083
(0x43B)
0 R/W
✓
UINT 1 0 0x00: DIRECT
0x03: Window Mode
0x04: Hysteresis
Logic 2 1084
(0x43C)
0 R/W
✓
UINT 1 0 0x00: DIRECT
0x03: Window Mode
0x04: Hysteresis
Timer 1 mode 1085
(0x43D)
0 R/W
✓
UINT 1 0 0x00: Deactivated
0x01: On-delay timer
0x02: O󰀨-delay timer
0x03: On/O󰀨-delay timer
0x04: Pulse (one shot)
0x05: On-delay pulse timer
Timer 2 mode 1086
(0x43E)
0 R/W
✓
UINT 1 0 0x00: Deactivated
0x01: On-delay timer
0x02: O󰀨-delay timer
0x03: On/O󰀨-delay timer
0x04: Pulse (one shot)
0x05: On-delay pulse timer
Timer 1 setup 1087
(0x43F)
0 R/W
✓
UINT 2 1 1 to 30000 Unit: ms
Timer 2 setup 1088
(0x440)
0 R/W
✓
UINT 2 1 1 to 30000 Unit: ms
Output mode 1 1089
(0x441)
0 R/W
✓
UINT 1 0 0x00: Not inverted
0x01: Inverted
Output mode 2 1090
(0x442)
0 R/W
✓
UINT 1 0 0x00: Not inverted
0x01: Inverted
Timer 1.1 setup 1091
(0x443)
0 R/W
✓
UINT 2 1 1 to 30000 Unit: ms
Timer 2.1 setup 1092
(0x444)
0 R/W
✓
UINT 2 1 1 to 30000 Unit: ms
I/O Settings Ext. input for input
mode
1093
(0x445)
0 R/W
✓
UINT 1 0 0x00: Not inverted
0x01 Inverted
Main interface Device display 3584
(0x0E00)
0 R STRING 75 Format: Display 1,
Display 2, Display 3,
Display 4, Display 5
*3
Device buttons 3585
(0x0E01)
0 W UINT 1 0: Release
1: Push
Bit 0: Plus button
Bit 1: Minus button
Bit 2: Menu/OK button
Bit 3: Teach/ESC button
Device LEDs - Power
LED
3586
(0x0E02)
1 R UINT 1 0: o󰀨
1: on
2: blink 1 (1 Hz 50:50)
3: blink 2 (6 Hz 50:50)
4: blink 3 (4 Hz 25:75)
5: blink 4 (1 Hz 50:50)
6: blink 5 (1 Hz 90:10)
Device LEDs - Q1 LED 2 R UINT 1 0: o󰀨
1: on
2: blink 1 (1
Hz 50:50)
3: blink 2 (6
Hz 50:50)
4: blink 3 (4
Hz 25:75)
5: blink 4 (1
Hz 50:50)
6: blink 5 (1
Hz 90:10)
Device LEDs - Q2 LED
3 R UINT 1 0: o󰀨
1: on
2: blink 1 (1 Hz 50:50)
3: blink 2 (6 Hz 50:50)
4: blink 3 (4 Hz 25:75)
5: blink 4 (1 Hz 50:50)
6: blink 5 (1 Hz 90:10)
*1: R: Read only, W: Write only, R/W: Read/Write
*2: Executes a Find Me request for this product.
During the execution of operation due to a Find Me command, the Output 1 and Output 2 indicators blink
in orange.
*3: The display will be in one of the following formats.
Display 4
Display 1
Display 2
Display 4
Display 3
Display 5
