MT100 Multipoint Flow Meter OPERATION
Command 12: Read Message Contained Within Device
Byte
Format
Request Data Bytes
None
Response Data Bytes
0–11
Bitstring
Code
Class
Response Codes
0
Success
1–127
Description
Device ID No.
Description
No Command-Specific Errors
Undefined
Command 13: Read Tag, Descriptor, Date
Byte
Format
Description
Request Data Bytes
None
Response Data Bytes
0–5
Packed
Tag
6–17
Packed
Descriptor
18–20
Date
Date Code: Day, Month, Year
Code
Class
Description
Response Codes
0
Success
No Command-Specific Errors
1–127
Undefined
Command 14: Read Primary Variable (Flow) Transducer Information
Byte
Format
Description
Request Data Bytes
None
Response Data Bytes
0–2
Unsigned-24
Transducer Serial Number
3
Enum
Transducer Limits and Minimum Span Units Code
4–7
Float
Upper Transducer Limit
8–11
Float
Lower Transducer Limit
12–15
Float
Minimum Span
Code
Class
Description
Response Codes
0
Success
No Command-Specific Errors
1–127
Undefined
Command 15: Read Device Information
Byte
Format
Description
Request Data Bytes
None
Response Data Bytes
0
Enum
Flow Alarm Selection Code
1
Enum
Flow Transfer Function Code (not supported)
2
Enum
Flow Upper and Lower Range Value Units Code
3–6
Float
Flow Upper Range Value
7–10
Float
Flow Lower Range Value
11–14
Float
Flow Damping Value
15
Enum
Write Protect Code (not supported)
16
Enum
Reserved
17
Bits
Flow Analog Channel Flags (not supported)
Code
Class
Description
Response Codes
0
Success
No Command-Specific Errors
1–127
Undefined
Fluid Components International LLC 51
