OPERATION MT100 Multipoint Flow Meter
Command 16: Read Final Assembly Number
Byte
Format
Description
Request Data Bytes
None
Response Data Bytes
0–2
Unsigned-24
STAK ELECT ASSY #
Code
Class
Description
Response Codes
0
Success
No Command-Specific Errors
1–127
Undefined
Command 17: Write Message Into Device
Byte
Format
Description
Request Data Bytes
0–23
Packed
Message String Used by Master
Response Data Bytes
1
0–23
Packed
Message String
Code
Class
Description
Response Codes
0
Success
No Command-Specific Errors
1–127
Undefined
Note: 1. The value returned in the response data bytes reflects the value actually used by the field device.
Command 18: Write Tag, Descriptor, Date
Byte
Format
Description
Request Data Bytes
0–5
Packed
Tag
6–17
Packed
Descriptor Used by Master
18–20
Date
Date Code Used by Master
Response Data Bytes
1
0–5
Packed
Tag
6–17
Packed
Descriptor
18–20
Date
Date Code: Day, Month, Year
Code
Class
Description
Response Codes
0
Success
No Command-Specific Errors
1–127
Undefined
Note: 1. The value returned in the response data bytes reflects the value actually used by the field device.
Command 19: Write Final Assembly Number
Byte
Format
Description
Request Data Bytes
0–2
Unsigned-24
STAK ELECT ASSY #
Response Data Bytes
1
0–2
Unsigned-24
STAK ELECT ASSY #
Code
Class
Description
Response Codes
0
Success
No Command-Specific Errors
1–127
Undefined
Note: 1. The value returned in the response data bytes reflects the value actually used by the field device.
Command 20: Read Long Tag
Byte
Format
Description
Request Data Bytes
None
Response Data Bytes
0–31
Latin-1
Long Tag
Code
Class
Description
Response Codes
0
Success
No Command-Specific Errors
1–127
Undefined
