MT100 Multipoint Flow Meter OPERATION
Command 150: Write “Write Protect Mode”
Byte
Format
Description
Request Data Bytes
0
Unsigned-8
Write Protect Mode: 0x00 = Disable; 0x01 = Enable
Response Data Bytes
0
Unsigned-8
Write Protect Mode: 0x00 = Disable; 0x01 = Enable
Code
Class
Description
Response Codes
0
Success
No Command-Specific Errors
1
Undefined
2
Data Entry Error
Invalid Selection
3–4
Undefined
5
Data Entry Error
6
Misc. Error
7
Mode Error
8–15
Undefined
16
Mode Error
17–127
Undefined
Command 151: Read Calibration Flow Limits
Byte
Format
Description
Request Data Bytes
None
Response Data Bytes
0–3
Float
Flow Lower Limit Value
4–7
Float
Flow Upper Limit Value
Code
Class
Description
Response Codes
0
Success
No Command-Specific Errors
1–127
Undefined
Command 154: Read Calibration Temperature Limits
Byte
Format
Description
Request Data Bytes
None
Response Data Bytes
0–3
Float
Temperature Lower Limit Value
4–7
Float
Temperature Upper Limit Value
Code
Class
Description
Response Codes
0
1–127
Success
No Command-Specific Errors
Undefined
Command 157: Read Calibration Pressure Limits
Byte
Format
Request Data Bytes
None
Response Data Bytes
0–3
Float
4–7
Float
Description
Pressure Lower Limit Value
Pressure Upper Limit Value
Code
Class
Description
Response Codes
0
Success
No Command-Specific Errors
1–127
Undefined
Command 155: Read KFactors
Byte
Format
Description
Request Data Bytes
None
Response Data Bytes
0–3
Float
KFactor1
4–7
Float
KFactor2
8–11
Float
KFactor3
12–15
Float
KFactor4
Code
Class
Description
Response Codes
0
Success
No Command-Specific Errors
1–127
Undefined
