OPERATION MT100 Multipoint Flow Meter
Command 159: Write Factory Restore
Byte
Format
Description
Request Data Bytes
1
0
Unsigned-8
0x00 for Factory Restore
Response Data Bytes
0
Unsigned-8
0x00 for Factory Restore
Code
Class
Description
Response Codes
0
Success
No Command-Specific Errors
1–5
Undefined
6
Misc. Error
Device-Specific Command Error
7
Mode Error
In Write Protect Mode
8–15
Undefined
16
Mode Error
Access Restricted
17–127
Undefined
Note: 1. Send Command 159 with a “0” byte to reload the instrument’s factory default programming.
