MT100 Multipoint Flow Meter OPERATION
Command 163: Write (4-20 mA) Output Channel #2 Parameters
Byte
Format
Description
Request Data Bytes
0–1
Unsigned-16
D/A Setting for 4 mA Out (OUTZ2)
2–3
Unsigned-16
D/A Setting for 4 mA Out (OUTF2)
4
Unsigned-8
Channel #2 Out Variable
Response Data Bytes
0–1
Unsigned-16
D/A Setting for 4 mA Out (OUTZ2)
2–3
Unsigned-16
D/A Setting for 4 mA Out (OUTF2)
4
Unsigned-8
Channel #2 Out Variable
Code
Class
Description
Response Codes
0
Success
No Command-Specific Errors
1
Undefined
2
Data Entry Error
Invalid Selection
3–4
Undefined
5
Data Entry Error
Too Few Bytes Received
6
Misc. Error
Device-Specific Command Error
7
Mode Error
In Write Protect Mode
8–15
Undefined
16
Mode Error
Access Restricted
17–127
Undefined
Command 164: Read (4-20 mA) Output Channel #2 Parameters
Byte
Format
Description
Request Data Bytes
None
Response Data Bytes
0–1
Unsigned-16
D/A Setting for 4 mA Out (OUTZ2)
2–3
Unsigned-16
D/A Setting for 4 mA Out (OUTF2)
4
Unsigned-8
Channel #2 Out Variable
Code
Class
Description
Response Codes
0
Success
No Command-Specific Errors
1–5
Undefined
6
Error
Device-Specific Command Error
7–127
Undefined
Command 166: Write (4-20 mA) Output Channel #3 Parameters
Byte
Format
Description
Request Data Bytes
0–1
Unsigned-16
D/A Setting for 4 mA Out (OUTZ3)
2–3
Unsigned-16
D/A Setting for 4 mA Out (OUTF3)
4
Unsigned-8
Channel #3 Out Variable
Response Data Bytes
0–1
Unsigned-16
D/A Setting for 4 mA Out (OUTZ3)
2–3
Unsigned-16
D/A Setting for 4 mA Out (OUTF3)
4
Unsigned-8
Channel #3 Out Variable
Code
Class
Description
Response Codes
0
Success
No Command-Specific Errors
1
Undefined
2
Data Entry Error
Invalid Selection
3–4
Undefined
5
Data Entry Error
Too Few Bytes Received
6
Misc. Error
Device-Specific Command Error
7
Mode Error
In Write Protect Mode
8–15
Undefined
16
Mode Error
Access Restricted
17–127
Undefined
Fluid Components International LLC 63
