OPERATION MT100 Multipoint Flow Meter
Command 167: Read (4-20 mA) Output Channel #3 Parameters
Byte
Format
Description
Request Data Bytes
None
Response Data Bytes
0–1
Unsigned-16
D/A Setting for 4 mA Out (OUTZ3)
2–3
Unsigned-16
D/A Setting for 4 mA Out (OUTF3)
4
Unsigned-8
Channel #3 Out Variable
Code
Class
Description
Response Codes
0
Success
No Command-Specific Errors
1–5
Undefined
6
Error
Device-Specific Command Error
7–127
Undefined
Command 170: Read Bank #1 Sensor Variables
Byte
Format
Description
Request Data Bytes
None
Response Data Bytes
0–3
Float
Flow Value Sensor #1
4–7
Float
Temperature Value Sensor #1
8–11
Float
Pressure Value Sensor #1
12–15
Float
Flow Value Sensor #2
16–19
Float
Temperature Value Sensor #2
20–23
Float
Pressure Value Sensor #2
24–27
Float
Flow Value Sensor #3
28–31
Float
Temperature Value Sensor #3
32–35
Float
Pressure Value Sensor #3
36–39
Float
Flow Value Sensor #4
40–43
Float
Temperature Value Sensor #4
44–47
Float
Pressure Value Sensor #4
Code
Class
Description
Response Codes
0
Success
No Command-Specific Errors
1–5
Undefined
6
Error
Device-Specific Command Error
7–127
Undefined
Command 172: Read Bank #2 Sensor Variables
Byte
Format
Description
Request Data Bytes
None
Response Data Bytes
0–3
Float
Flow Value Sensor #5
4–7
Float
Temperature Value Sensor #5
8–11
Float
Pressure Value Sensor #5
12–15
Float
Flow Value Sensor #6
16–19
Float
Temperature Value Sensor #6
20–23
Float
Pressure Value Sensor #6
24–27
Float
Flow Value Sensor #7
28–31
Float
Temperature Value Sensor #7
32–35
Float
Pressure Value Sensor #7
36–39
Float
Flow Value Sensor #8
40–43
Float
Temperature Value Sensor #8
44–47
Float
Pressure Value Sensor #8
Code
Class
Description
Response Codes
0
Success
No Command-Specific Errors
1–5
Undefined
6
Error
Device-Specific Command Error
7–127
Undefined
