MT100 Multipoint Flow Meter OPERATION
Command 174: Read Bank #3 Sensor Variables
Byte
Format
Description
Request Data Bytes
None
Response Data Bytes
0–3
Float
Flow Value Sensor #9
4–7
Float
Temperature Value Sensor #9
8–11
Float
Pressure Value Sensor #9
12–15
Float
Flow Value Sensor #10
16–19
Float
Temperature Value Sensor #10
20–23
Float
Pressure Value Sensor #10
24–27
Float
Flow Value Sensor #11
28–31
Float
Temperature Value Sensor #11
32–35
Float
Pressure Value Sensor #11
36–39
Float
Flow Value Sensor #12
40–43
Float
Temperature Value Sensor #12
44–47
Float
Pressure Value Sensor #12
Code
Class
Description
Response Codes
0
Success
No Command-Specific Errors
1–5
Undefined
6
Error
Device-Specific Command Error
7–127
Undefined
Command 176 Read Bank #4 Sensor Variables
Byte
Format
Description
Request Data Bytes
None
Response Data Bytes
0–3
Float
Flow Value Sensor #13
4–7
Float
Temperature Value Sensor #13
8–11
Float
Pressure Value Sensor #13
12–15
Float
Flow Value Sensor #14
16–19
Float
Temperature Value Sensor #14
20–23
Float
Pressure Value Sensor #14
24–27
Float
Flow Value Sensor #15
28–31
Float
Temperature Value Sensor #15
32–35
Float
Pressure Value Sensor #15
36–39
Float
Flow Value Sensor #16
40–43
Float
Temperature Value Sensor #16
44–47
Float
Pressure Value Sensor #16
Code
Class
Description
Response Codes
0
Success
No Command-Specific Errors
1–5
Undefined
6
Error
Device-Specific Command Error
7–127
Undefined
