2.1 The entire system for the CMMP-AS-...-M0
A motor controller CMMP-AS-...-M0 entire system is shown in è Fig. 2.1 è Page 14. For operation of
the motor controller, the following components are required:
– Mains power switch
– FI circuit breaker (RCD), all-current sensitive 300 mA
– Automatic circuit breaker
– Power supply 24 V DC
– Motor controller CMMP-AS-...-M0
– Motor with motor and encoder cables
A Windows PC with USB or Ethernet connection is required for parametrisation.
Observe the instructions regarding mains fuses in è Chapter 4.
