5 Commissioning
Festo – GDCP-CMMP-M0-HW-EN – 1511c – English 57
5.4 Connect motor controller CMMP-AS-...-M0 to the power supply
Warning
Danger of electric shock.
– When cables are not mounted to the plugs [X6] and [X9].
– When connecting cables are disconnected when powered.
Touching live parts causes severe injuries and can lead to death.
The product may only be operated in a built-in status and when all protective measures
have been initiated.
Before touching live parts during maintenance, repair and cleaning work and when there
have been long service interruptions:
1. Switch off power to the electrical equipment via the mains switch and secure it
against being switched on again.
2. After switch-off, wait at least 5 minutes discharge time and check that power is
turned off before accessing the controller.
1. Make sure that the power supply is switched off.
2. Connect the PE cable of the mains supply to the PE earth socket.
3. Insert the PHOENIX plug into the socket [X9] of the motor controller.
4. Connect 24 V connections with appropriate power pack.
5. Make the network power supply connections.
6. Check all plug connectors once again.
5.5 Connecting a PC
1. Connect PC via USB è 4.11.2 USB [X19] or Ethernet è 4.11.3 Ethernet TCP/IP [X18] to the motor
controller.
