4 Electrical installation
Festo – GDCP-CMMP-M0-HW-EN – 1511c – English 47
4.11.3 Ethernet TCP/IP [X18]
The equipment of the series CMMP-AS-...-M0 have a USB interface for parametrisation.
The following functions are supported:
– Point-to-point communication between PC and motor controller for parametrisation
– Complete parametrisation of theCMMP-AS-...-M0 via FCT
– Communication from one PC or one PLC to several CMMP-AS-...-M0 that are located in the same
local network for the purpose of monitoring, adaptation of the parametrisation or also process con
trol of the controller via Modbus TCP.
Note
Unauthorised access to the device can cause damage or malfunctions.
When connecting the device to a network:
Protect the network from unauthorised access.
Measures for protecting the network include:
– Firewall
– Intrusion Prevention System (IPS)
– Network segmentation
– Virtual LAN (VLAN)
– Virtual private network (VPN)
– Security at physical access level (Port Security).
For further information è Guidelines and standards for security in information techno
logy, e.g. IEC 62443, ISO/IEC 27001.
Interface design
The interface in the device is designed as an 8P8C socket (RJ45).
The connection has two LEDs with the following function:
– Yellow Physical Link Detect (network connection available)
– Green Data Connection (data connection / data exchange)
The interface is designed to conform to the IEEE 802.3u specification. Cables of type FTP5 or high-order
must be used with 100Base-TX. The interface supports the autosensing function for automatic identi
fication of the connected cable. Both standard patch cables (1:1) and Crosslink (crossed) cables can be
used.
Supported services
The following services are supported by the Ethernet interface:
– TCP/IP
– UDP/IP
– DNS (ARP and BOOTP)
– DHCP
– AutoIP
–TFTP
TFTP must be activated separately in Windows if necessary and a pass rule defined in the
Firewall.
