4 Electrical installation
Festo – GDCP-CMMP-M0-HW-EN – 1511c – English 31
Controller CMMP-AS-…-M0
Pin no.
x1
AIN0
#AIN0
AIN1
AIN2
+VREF
AGND
AOUT0
AOUT1
AGND
100 mA
max!
+24 V DC
DIN 0
DIN9
DOUT0
DOUT3
GND24
100 mA
max!
PE PE
GND24
+24 V DC
AGND
AIN0
#AIN0
AIN1/AIN2
AGND
AGND
+VREF
AGND
+15 V DC
AMON0/1
AGND
DINX
AGNDGND
GND24
GND
GND
GND24
+24 V DC
DOUTX
Plug housing
2
15
3
16
4
14
17
5
14
1
18
19
11
24
13
6
Fig. 4.4 Basic circuit diagram of connection [X1]
Control cable and Sub-D plug connector è www.festo.com/catalogue.
