A Technical appendix
80 Festo – GDCP-CMMP-M0-HW-EN – 1511c – English
HIPERFACE encoders
Type Protocol Interface Comment
SCS60, 70
SCM60, 70
HIPERFACE [X2B] Stegmann single-/multi-turn encoder
with analogue incremental signal
sine/cosine periods 512. Max. revolu
tions multi-turn: ±2048 R
SRS 50, 60, 64
SCKxx
SRM 50, 60, 64
SCLxx
HIPERFACE [X2B] Stegmann single-/multi-turn encoder
with analogue incremental signals.
Sine/cosine periods 1024. Max. re
volutions multi-turn: ±2048 R
SKS36
SKM36
HIPERFACE [X2B] Stegmann single-/multi-turn encoder
with analogue incremental signals.
Sine/cosine periods 128. Max. re
volutions multi-turn: ±2048 R
SEK37, 52
SEL37, 52
HIPERFACE [X2B] Stegmann single-/multi-turn encoder
with analogue incremental signals.
Sine/cosine periods 16. Max. revolu
tions multi-turn: ±2048 R
L230 HIPERFACE [X2B] Stegmann absolute linear encoder
with analogue incremental signal
measurement step: 156.25 µm.
Measuring length max. approx. 40 m.
Tab. A.35 Supported HIPERFACE encoders
BiSS encoder
Type Protocol Interface Comment
ME 20.20-0.40 BiSS [X2B] ELGO magnetic incremental linear en
coder (use e.g. for ELGL-LAS...)
Tab. A.36 Supported BiSS encoders
