A. Specifications and index
A-4
Festo Festo P .BE CP FB13-E-EN en 9910c
Operating voltage for solenoid valves on CP valve terminal
Pin 2
Operating voltage connection
– Rated value
– Tolerance:
24 V DC,
20.4 .. 26.4 V
Current consumption
– Pin 2 node FB13-E
Sum of all switched-on CP solenoid valves; see
manual “CP pneumatic s”
Residual ripple 4 Vpp (within tolerance)
Bridging time during drop in logic voltage 20 ms
Field bus
Design RS 485, floating
Tra nsmisssion type serial asynchronous, half-duplex
Protocols PROFIBUS-DP
Baud rate 9.6...12000 kBaud automatic baud rate recogni-
tion
Cable length (depending on baud rate and cable
type)
up to 23.8 km
Cable type (dependig on cable length and field
bus baud rate set)
see controller manual
Loading capacity of positive power supply (P5V)
pin 6
max. 40 mA
Elec tromagnetic compatibility
– Interference emitted tested as per E N 55011
– Immunity against interference
tested as per EN 50082-2
limit class B
