2. Commissioning
2-11
Festo Festo P .BE CP FB13-E-EN en 9910c
Thefollowingtableshowsasummaryofthepossibleentries
for the valve terminal in compact mode.
with input modules
Last used st ring
number
Number of
input bytes
Sum identifier (decimal)
0 2 017 16DE
1 4 019 32DE
2 6 021 –
3 8 023 –
with output modules or valve terminals
Last used st ring
number
Number of
output bytes
Sum identifier (decimal)
0 2 033 16DA
1 4 035 32DA
2 6 037 –
3 8 039 –
Fig. 2/5: Compact mode: Possible configuration of the in-
puts and outputs
