2. Commissioning
2-10
Festo Festo P .BE CP FB13-E-EN en 9910c
Compact mode
Please note
Observe the sequence “inputs before outputs” in compact
mode,ifbothinputsandoutputsareinstalledinaCPsys-
tem.
In compact mode configure the sum of the input bytes and
the sum of the output bytes separately and independently
of each other (see fig. 2/9). The following applies here:
CP valve terminals occupy two output bytes irrespective of
the number of valves fitted.
– Assign the DP identifiers in ascending order without gaps.
No field may remain unused. Enter: inputs before out-
puts.
– If only output modules or CP valve terminals are fitted:
enter their DP identifiers in line 0.
– The string assigned with the highest number of inputs or
outputs defines the sum of input or output bytes.
– Non-existent CP valve terminals, input modules or output
modules occupy input or output bytes, if a higher string is
assigned with inputs or outputs.
Maximum configuration in compact mode:
023 039 8 input bytes and 8 output bytes
