2. Commissioning
2-9
Festo Festo P .BE CP FB13-E-EN en 9910c
Standard mode
In standard mode configure 16 outputs and 16 inputs per as-
signed string. DP identifier 049 or 16DX for each assig ned string
The following table shows a summary of the possible entries for
the valve terminal in standard mode.
Last used
string number
Number of
bytes for
input/outputs
Individual identifier
0 2 16DX
1 4 16DX, 16DX
2 6 16DX, 16DX, 16DX
3 8 16DX, 16DX, 16DX, 16DX
Fig. 2/3: S tandard mode Possible configuration of the in-
puts and outputs
The last used string is decisive for the number of DP ident-
ifiers, even if numerically lower strings are notassigned physi-
cally (see manual “CP system, installation and commission-
ing”).
Example:
CP system with 3 strings, a total of 3 input modules and 3
output modules, highest assigned string number = 2.
DP identifier Comment
0 16DX Input module and output module of
string 0
1 16DX Input module and output module of
string 1
2 16DX Input module and output module of
string 2
Fig. 2/4: Configuration in standard mode
