2. Commissioning
2-31
Festo Festo P .BE CP FB13-E-EN en 9910c
Examples of addressing in standard mode
Addresses of the CP system: 12
String assignment
of the CP system
DP identifier I/O address
(IN/OUT)
String 0
16 outputs and 16 elec-
trical inputs
049 O 20.0 21.7
I 20.0 ... 21.7
String 1
not assigned
049 O 22.0 23.7
I 22.0 ... 23.7
String 2
16 outputs and 16 elec-
trical inputs
049 O 24.0 ... 25.7
I 24.0 ... 25 .7
String 3
not assigned
– Address range can be
used for other bus
slaves
See also fig. 2/11
