Festo CP Series User Manual

Electrical components (CP terminal with individual or CP connection)
Electromagnetic compatibility
of the CP terminal with CP connection
Interference emission:
Resistance to interference
Tested as per EN 55011, limit value class B
Tested as per EN 50082–2
Relay plate Consisting of 2 relay for controlling 2
electrically isolated outputs
Operating voltage
Tolerance:
– CP terminal with CP connection
– CP terminal with IC connection
DC 24 V
20.4–26.4 V
18.0–26.4 V
Power consumption at 24 V CPV10 CPV14 CPV18
CPvalve terminal all connection
variations: – per valve plate
CP valve terminal with CP connection:
– per relay plate
CP valve terminal with IC connection:
– additionally per individual connector plug
0.52 W
1.2 W
0.26 W
0.85 W
1.2 W
0.26 W
1.5 W
---------
0.26 W
Input current consumption of
electronic components:
CP terminal with CP connection
20 mA 25 mA
Switching times of the relay outputs
(with normal voltage)
– pickup time
– drop-off tiime
5 ms
2 ms
PLEASE NOTE
Data on the electrical components of the CP terminal
with multipin or ASI connection is supplied with the
relevant product.
A. Technical appendix
A-8 CPV... 9802
