2.1.2 Fitting onto a hat rail
PLEASE NOTE
In order to fit the CP valve terminal onto a hat rail
you require the following fitting kit:
– For CPV10/14 terminals:
fitting kit CPV10/14-VI-BG-NRH-35
– For CPV18 terminals:
fitting kit CPV18-VI-BG-NRH-35
These kits consist of 2 brackets, 2 or 4 M4 x 10 self-
cutting screws (CPV10/14) or M5 x 10 (CPV18) and
2 M4 x 10 screws with clamping pieces and springs.
Proceed as follows:
• Make sure that your fastening surface can support
the weight of the CP valve terminal.
• Fit one of the following hat rails:
Hat rail for CPV10/14 terminal Hat rail for CPV18 terminal
support rail as per
EN 50022 - 35x7.5
(width 35 mm, height 7.5 mm)
support rail as per
EN 50022 - 35x15
(width 35 mm, height 15 mm)
• Make sure that there is enough room to connect the
power cables and the pneumatic tubing.
• Fasten the hat rail to the surface approximately every
100 mm.
2. Fitting
2-6 CPV... 9802
