Festo CP Series User Manual

A.2 Technical specifications
General
Permitted temperature range:
–storage
– operation
– medium
- 20 to + 70
o
C
- 5 to + 50
o
C
- 5 to + 50
o
C
Protection class as per EN 60 529 IP 65 (with FESTO accessories cable)
Relative humidity 90 % at 20
o
C or 40 % at 50
o
C
Corrosion protection Against industrial climate (as per FN940070)
Fitting position As desired
Tightening torques CPV10/14 CPV18
– Socket for IC connection
– Connecting socket for relay
outputs
– Fastening screw for wall support
or hat rail
– Screws for fastening CP terminal
to pneumatic multipin
– Electrical connector plate
– Earth connection
– tie rod
0.15 Nm
0.15 Nm
1.5 Nm
2.0 Nm
0.7 Nm
1.0 Nm
1st. stage 0.3 Nm
2nd. stage 2.0 Nm
4.0 Nm
4.0 Nm
3.0 Nm
1.0 Nm
1st. stage 0.3 Nm
2nd. stage 4.0 Nm
Materials
Plates, cover, pneumatic multiple
connector plate:
Seal:
AL, AL-GD, Ms, PAXMD6, PET, POM, PPS, ST,
NBR, HNBR
Oscillation
(as per DIN/IEC 68 part 2–6)
– Transport:
– Operation/use:
Shock:
(as per DIN/IEC 68 part 2–27)
3.5 mm travel at 2–9 Hz
1 g acceleration at 9–200 Hz
0.35 mm travel at 10–60 Hz
5 g acceleration at 60–150 Hz
30 g acceleration at 11 ms duration
A. Technical appendix
A-4 CPV... 9802
