Festo CP Series User Manual

General
Approximate weights (in kg) CPV10 CPV14 CPV18
Electrical connector plate with AS-i connection
- on CP valve terminals with 2 valve locations
- on CP valve terminals with 4 valve locations
0.085
0.110
0.130
0.175
0.275
0.355
Electrical connector plate with CP connection
- on CP valve terminals with 4 valve locations
- on CP valve terminals with 6 valve locations
- on CP valve terminals with 8 valve locations
0.145
0.180
0.200
0.230
0.250
0.300
0.375
0.450
0.540
Electrical connector plate with MP connection
- on CP valve terminals with 4 valve locations
- on CP valve terminals with 6 valve locations
- on CP valve terminals with 8 valve locations
0.110
0.140
0.165
0.170
0.230
0.275
0.400
0.425
0.515
End plates 0.160 0.280 0.740
Pneumatic multiple connector plate
- on CP valve terminals with 2 valve locations
- on CP valve terminals with 4 valve locations
- on CP valve terminals with 6 valve locations
- on CP valve terminals with 8 valve locations
0.120
0.165
0.225
0.270
0.270
0.390
0.510
0.630
0.520
0.750
0.870
1.300
Relay plate 0.035 0.055 -----
Reserve plate 0.025 0.045 0.090
Isolating plate 0.025 0.045 0.090
Valve plates 0.65 0.110 0.280
