Festo CP Series User Manual

WARNING
Before undertaking installation or maintenance work,
switch off the following:
• the compressed air supply
• the power supply to the valve solenoid coils
You thereby avoid:
– uncontrolled movements of loose tubing
– unintentional movements of the connected actuators
– undefined switching states of the electronic compo-
nents
2.1 CP terminal with individual tubing
The CP terminal with individual tubing has been des-
igned for integration in a system or machine which is to
be fitted as follows:
Fitting
variants
– Fitting onto a wall
– Fitting on a hat rail
– Fitting with feet
PLEASE NOTE
If your application is subjected to vibration in excess
of the following values:
– 0.15 mm travel at 10-58 Hz
– 2 g acceleration at 58-150 Hz
the CPV14 or CPV 18 terminals should be mounted
on a wall or with feet.
2. Fitting
CPV... 9802 2-3
