Turn the component forwards around the front tie
rod.
1
2
Front tie bolt
Rear tie bolt
Fig. 5/2: Position of the tie bolt
Pull the component so that it snaps out of the front
tie bolt.
5.1.2 Fitting components into the valve locations
Proceed as follows:
1. Fitting components
Check that the seals are fitted correctly between the
terminal components. They must lie accurately in the
appropriate seal grooves.
1
2
5. Maintenance and conversion
CPV... 9802 5-7
