3.2 Connecting the CP valve terminal
PLEASE NOTE
•
If valves are not used, seal the work connections
2 and 4 with blind plugs.
•
Depending on the tool you are using, observe
the following sequence when you connect the
work lines:
- if using a socket head wrench, you can connect
the work lines in any sequence.
- if using an external socket head wrench, you
must connect the work lines from left to right
(room for wrench).
In order to guarantee optimum efficiency of your CP
valve terminal, we recommend that the compressed air
and, if necessary, the exhaust lines be connected on
both sides in the following cases:
– when large-volume cylinders are to be operated at
high speed
– when several valves are switched simultaneously to
through flow
PLEASE NOTE
•
Connect the supply pressure to both sides of the
end plates or pneumatic multiple connector plate,
if the CP terminal is operated with two pressure
zones.
3. Installation
CPV... 9802 3-5
