Festo CP Series User Manual

CAUTION
Operate the CP valve terminal only with the medium
described below:
– If possible use non-lubricated auxiliary pilot air
(connection 12/14). Otherwise the oil content must
not exceed 3-5 drops per 1000 l of air consumed.
Use here hydraulic oil of type DIN 51524-HL32.
Observe the specifications on special oil for
maintenance units in the Festo Pneumatics
Catalogue.
– In the case of CP valve terminals with internally
branched auxiliary pilot air the above mentioned
instruction also applies to the supply air
(connection 1/11).
Pneumatic components
Medium
Compressed air, filtered (40 µm), lubricated
(Öl: VG 32) or non-lubricated/vacuum
Design Valve plates with spool valves
Pressure range CPV10/14 CPV18
– with internal auxiliary pilot air taken
from 1 or 11
– with externally supplied auxiliary
pilot air
– 12/14
3-8 bar
- 0.9-10 bar
3-8 bar
3-8 bar
- 0.9-10 bar
3.5-8 bar (ident. code G)
2-8 bar (ident. code J)
3-8 bar (all other valves),
Manual override pushing or locking
PLEASE NOTE
The flow rates of the valves are reduced by the
screw couplings of the pneumatic connections.
A. Technical appendix
A-6 CPV... 9802
