Festo CP Series User Manual

Wall cutout dimensions for CP valve terminals with
extended pneumatic multiple connector plate
CPV10/18:
CPV14:
CPV10 terminal CPV14 terminal CPV18 terminal
1
2
3
4
5
6
7
8
9
0
!
"
30 mm + 9
73 mm
R12
6.3 mm
----------------------------------
----------------------------------
----------------------------------
21 mm
10 mm x number of plates
21.5 mm
18.5 mm
Diameter 6.5 mm
40 mm + 9
89 mm
R14
9.0 mm
4.7 mm
5.55 mm
R8
26 mm
14 mm x number of plates
29.5 mm
29.5 mm
Diameter 6.5 mm
60 mm + 9
118 mm
R22
15 mm
-----------------------------------
-----------------------------------
-----------------------------------
35.5 mm
18 mm x number of plates
44 mm
44 mm
Diameter 6.5 mm
Fig. 2/6: Wall cutout dimensions for the extended pneumatic multiple
connector plate
9
88
2
3
1
4
5
"
7
6
0
!
9
8
8
1
4
"
2
3
!
0
2. Fitting
CPV... 9802 2-13

Festo CP Series Specifications

General

Type	Controller
Series	CP
Category	Controller
Manufacturer	Festo
Operating Voltage	24 V DC
Protection Class	IP20
Communication Interface	CANopen, PROFINET
Programming Environment	Festo Automation Suite
Number of Axes	Varies (depending on model, typically up to 6 or more)
