Festo CP Series User Manual

LED display of valves
There is a yellow LED for each valve solenoid coil. This
LED shows the switching status of the valve solenoid
coil when the CP valve terminal is ready to operate.
PLEASE NOTE
Observe the assignment of the LED to the
appropriate manual override:
With IC connection:
– LED in front plug to
upper manual override (14)
– LED in rear plug to
lower manual override (12)
With MP, AS-i or CP connection:
– lower LED in plug cover to
upper manual override (14)
– upper LED in plug cover to
lower manual override (12)
4. Commissioning
CPV... 9802 4-11

Festo CP Series Specifications

General

Type	Controller
Series	CP
Category	Controller
Manufacturer	Festo
Operating Voltage	24 V DC
Protection Class	IP20
Communication Interface	CANopen, PROFINET
Programming Environment	Festo Automation Suite
Number of Axes	Varies (depending on model, typically up to 6 or more)
