IO-Link
99
Index.
Subindex
Name Description Data type
(length)
User access
1)
U = User
M = Maintenance
personnel
S = Specialist
U M S
ProcessDataOutput (Master è Device)
0x0029.1
(41.1)
Move "In" Control command for executing
the motion "Mov
In
" to the
"Lim
In
(Ref)" end position.
– The control command only
works in combination with the
bits
–
0x0029.2: move "Out"
– 0x0029.5: move "Inter-
mediate"
è
15.2.5 Control point-to-
point operation via IO-Link.
– Corresponds to the function of
digital input 1 (DI1).
BooleanT
(1 bit)
R/W R/W R/W
0x0029.2
(41.2)
Move "Out" Control command for executing
the motion "Mov
Out
" to the
"Lim
Out
" end position.
– The control command only
works in combination with the
bits
–
0x0029.1: move "In"
– 0x0029.5: move "Inter-
mediate"
è
15.2.5 Control point-to-
point operation via IO-Link.
– Corresponds to the function of
digital input 2 (DI2).
BooleanT
(1 bit)
R/W R/W R/W
