FCP-75 Manual — P/N:LS10147-003FK-E:A 3/17/2021 119
11.2 SIA / FCP-75 Panels PI Modifier Reporting:
Events are sent to the central station as a variable length string:
The Event Format is:
EEZZZZ
Where the Event Format is defined as follows:
1. The Account Number is sent using an account block that is separate from the event block.
2. Multiple events can be sent within a single event block. Events are separated by a “/” character.
3. Event parameter can be either a zone, point or module number.
Voice Aux Status 1 Switch is Trouble Re-
stored
pi Exp. ID UJ Point # UJNNXXPPPP 3 379 Exp. ID Point #
Voice Aux Status 1 Switch is Disabled pi Exp. ID UB Point # UBNXXPPPP 1 580 Exp. ID Point #
Voice Aux Status 1 Switch is Enabled pi Exp. ID UU Point # UUNXXPPPP 3 580 Exp. ID Point #
Voice Aux Status 2 Switch is Trouble pi Exp. ID UT Point # UTNNXXPPPP 1 379 Exp. ID Point #
Voice Aux Status 2 Switch is Trouble Re-
stored
pi Exp. ID UJ Point # UJNNXXPPPP 3 379 Exp. ID Point #
Voice Aux Status 2 Switch is Disabled pi Exp. ID UB Point # UBNNXXPPPP 1 580 Exp. ID Point #
Voice Aux Status 2 Switch is Enabled pi Exp. ID UU Point # UUNNXXPPPP 3 580 Exp. ID Point #
Water flow switch alarm pi Exp. ID SA Point # SANNXXPPPP 1 113 Exp. ID Point #
Water flow switch alarm restore pi Exp. ID SH Point # SHNNXXPPPP 3 113 Exp. ID Point #
Water flow switch disabled pi Exp. ID SB Point # SBNNXXPPPP 1 571 Exp. ID Point #
Water flow switch enabled pi Exp. ID SU Point # SUNNXXPPPP 3 571 Exp. ID Point #
Water flow switch trouble pi Exp. ID ST Point # STNNXXPPPP 1 373 Exp. ID Point #
Water flow switch trouble restore pi Exp. ID SJ Point # SJNNXXPPPP 3 373 Exp. ID Point #
Zone-based AUX1 switch alarm pi Exp. ID UA Point # UANNXXPPPP 1 140 Exp. ID Point #
Zone-based AUX1 switch alarm restore pi Exp. ID UH Point # UHNNXXPPPP 3 140 Exp. ID Point #
Zone-based AUX1 switch disabled pi Exp. ID UB Point # UBNNXXPPPP 1 571 Exp. ID Point #
Zone-based AUX1 switch enabled pi Exp. ID UU Point # UUNNXXPPPP 3 571 Exp. ID Point #
Zone-based AUX1 switch trouble pi Exp. ID UT Point # UTNNXXPPPP 1 373 Exp. ID Point #
Zone-based AUX1 switch trouble restore pi Exp. ID UJ Point # UJNNXXPPPP 3 373 Exp. ID Point #
Zone-based AUX2 switch alarm pi Exp. ID UA Point # UANNXXPPPP 1 140 Exp. ID Point #
Zone-based AUX2 switch alarm restore pi Exp. ID UH Point # UHNNXXPPPP 3 140 Exp. ID Point #
Zone-based AUX2 switch disabled pi Exp. ID UB Point # UBNNXXPPPP 1 571 Exp. ID Point #
Zone-based AUX2 switch enabled pi Exp. ID UU Point # UUNNXXPPPP 3 571 Exp. ID Point #
Zone-based AUX2 switch trouble pi Exp. ID UT Point # UTNNXXPPPP 1 373 Exp. ID Point #
Zone-based AUX2 switch trouble restore pi Exp. ID UJ Point # UJNNXXPPPP 3 373 Exp. ID Point #
System-based Wireless Gateway Trouble pi Exp. ID UT Point # UTNNXXPPPP 1 373 Exp. ID Point #
System-based Wireless Gateway
Trouble - restore
pi Exp. ID UJ Point # UJNNXXPPPP 3 373 Exp. ID Point #
Wireless Gateway Trouble pi Exp. ID UT Point # UTNNXXPPPP 1 373 Exp. ID Point #
Wireless Gateway Trouble restore pi Exp. ID UJ Point # UJNNXXPPPP 3 373 Exp. ID Point #
SIA Reporting Format Contact ID Reporting Format
SIA pi Modifier SIA
Event Description Module ID
# (If Any)
SIA
Event
Codes
Parameter Fixed Length
Format NN - panel
ID
XX- SBUS ID
ZZZ- Zone #
PPPP- Point #
GGG- Group #
E- Emergency #
RRRR-Receiver #
Qualifier Event
Code
Group # Contact #
Table 11.2 Reporting Formats Table (Continued)
Code Event Code Description
EE
Event Code (2 characters)
ZZZZ Event parameter (up to four digits – not zero filled)
